- 4 -
2.0 Unpacking and Installation
Note: Do not throw away the box or packing materials.
Check the box and the contents for any signs of damage that may have happened during shipment. Carefully unpack
and check the contents.
The SY-765 package contains:
1 SY-765 terminal
Mounting panel/back plate
1 RJ-45 -> DB9F connector.
1 Product CD with the manuals and other tools.
2.1 Location/Site Requirements
The terminal c
an be installed in any normal office or factory environment. Controlled environments are not required
for proper operation of the terminal. However, installing and operating the terminal under adverse conditions may
affect the functionality of the unit.
2.1.1 Selecting a Location
Consider the
following environmental factors that may affect the operation of the terminal, when considering a
location:
• The cable should not be i
nstalled near EMI (Electromagnetic Interference) sources, such as:
o Motors, generators, alternators and transformers.
o Air conditioners, elevators, etc.
o Radio/Television transmitters, signal generators and internal communication networks.
• Cables should not be within:
o 30 cm. (1 ft.) from 5 KVA power lines or less.
o 60 cm. (2 ft.) from 5-10 KVA power lines.
o 1.5 meters (5 ft.) of power lines exceeding 10 KVA.
• Cables should not run parallel to power lines for more than 15 m. (49 ft.)
Four Phillips flat head 3.5x30mm and anchors, for terminal mounting purpose.
