Synel 765 - Appendix - C Error Messages; Error Messages

Appendix – C
Error Messages
Code Error Message
000 UNKNOWN ERROR
107 TRY AGAIN
108 TIME OUT
110 USER ID EXISTS
112 CHECK USER ID
116
CONTINUE
117
CMD UNSUPPORTED
118
INVALID USER ID
119
AUTO ASSIGN ID
120
TIMEOUT MATCH
Appendix – D
Internal Wiring Diagrams
D.1 Bells and Access
D 1.1 Signal Control
With the SY-765’s internal relay, the terminal can control a 30 VDC, 1 Amp dry-contact circuit. The signal
control relay can be turned on by both a specific employee badge/number for access control or by time of
day for bell ringing. The duration time is also programmable.
- 23 -
