Chapter 2: Hardware Setup
4
Insert the new memory module in the slot:
a
Align the notch on the gold edge of the module with the notch in the slot.
b
Tilt the card and insert the module into the slot. Make sure the module is properly inserted.
c
Push down on the memory module with moderate pressure until you hear a click.
l
Important:
You must utilize the same type of memory on all slots. The default memory is non-ECC SO-DIMM DDR4.
If you expand utilizing ECC SO-DIMM DDR4 memory, you must remove the original.
Note:
• Hold the memory module by its edges, and do not touch the gold connectors.
• When memory capacity is changed, the device will perform a memory check upon the next start up. This will
prolong the start up time by up to ten minutes. This behavior is normal and will only occur once.
• Synology will not provide complete product warranty or technical support if non-Synology RAM modules are used
for memory upgrade.
5
Replace the bottom panel. Replace and tighten the 2 screws you removed in step 3.
6
Reconnect the cables you removed in step 1, and then press and hold the power button to turn on your
Network Video Recorder.
To make sure Network Video Recorder recognizes the new memory capacity:
1
Install DiskStation Manager (DSM). (See the next chapter for more information.)
2
Log in to DSM as
admin
or a user belonging to the
administrators
group.
3
Check
Total Physical Memory
in
Control Panel
>
Info Center
.
If your Network Video Recorder does not recognize the memory or does not start up successfully, conrm that the
memory is installed correctly.
