SYNRAD OEM v30 Operator’s Manual Version 2
OEM v30 package outline drawings
Figure 4-18 OEM v30 fan-cooled package outline and mounting dimensions
.24
16.79
2.300
.800
.800
7.72 4.72
1.125
.563
6.28
2.906
.026
ACCESSORY MTG HOLES
4X 8-32 UNC-2B
.20
.500
BEAM EXIT
8-32 UNC-2B
.10
ACCESSORY MTG HOLE
S
3
DC INPUT
W/IN-LINE FUSE
INTERFACE A
(DB-9)
INTERFACE B (RJ-45)
LASE (RED)
READY (AMBER)
POWER (GREEN)
FAN POWER
.625
1.500 15.013
15.013
1.063 15.013
1.750 1.750
4.580
1/4-20 UNC
1/4-20 UNC
1/4-20 UNC
M6 X 1 ISO
M6 X 1 ISO
M6 X 1 ISO
6.3mm
1
1
1
2
2
2
2
2
2
C
L
NOTES:
HARDENED BALL MOUNTING POINT, 3X (Ø.1875 BALL BEARING)
.
THIS MOUNTING HOLE PATTERN USED FOR BOTTOM ACCESS FASTENING. BEAM PATH MAY NOT BE CENTERED OR PERPENDICULAR TO FACEPLATE APERTURE
.
1 2 3
B
B
DESCRIPTION:
FINISH:
MATERIAL:
REV ECO DATE
DESCRIPTION DB
TOLERANCES UNLESS NOTED:
2.0
ANGLE = ±
0.1
.x = ±
0.01
.xx = ±
0.005
.xxx = ±
.
PROPRIETARY
THIS DRAWING IS PROPRIETARY TO
SYNRAD INC. AND SHALL NOT BE
USED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT WRITTEN
PERMISSION OF SYNRAD INC.
PART NUMBER:
DWG/FILE NUMBER:
SHEET
ENG:
DRAWN BY:
DATE:
UNITS:
CATEGORY:
CHECKED BY:
DATE:
SIZE: B
FINISH CLASS:
APPROVED BY:
DATE:
SYNRAD INC. 4600 Campus Place Mukilteo, WA 98275 Phone: (425)349-3500 Fax: (425)349-3667
OUTLINE & MOUNTING, FAN-COOLED V30, OEM
8-Jan-09
300-18965-02
1
.
.
.
300-18965-02
of
1
.
D. DUVALL
Inches
.
.
.
DMD
RELEASE TO PRODUCTION
8-Jan-09
3952A
ADD NOTE 3
B
DMD
9-Sep-09
4107
.
.
.
.
.
