9. Installation
9.1 Inspection
Uponreceiptofthegoods,checkthatthepackagingand
thecontentsarenotvisiblydamaged.Otherwisecontact
SystemElectronics.
9.2 Fixing the units
Theunitisdesignedforeasymountingonaspecialrear
base(optionalforxingscopeonly),whichcanbexed
to any vertical surface by means of a pair of screws
(Figure9.2.1).
Figure 9.2.1 Mounting base and dimensions
Theunitiscoupledtothebasebymeansofaseriesof
trapezoidalteethplacedattheupperandlowerends.
Theteetharecoupledviatheslotsonthebase.
The upper slots of the base are located in mobile
elements held in place by springs.
The mounting base must be xed rst. The unit is
insertedbyplacingtheupperteethonthemobileslots,
exertingenoughpressuretoloadthespringsandallow
theinsertion of the lower teeth in their seats (Figure
9.2.2).
Disassemblytakesplaceinasimilarway:onepresses
upwardsfreeingthelowerteeth(Figure9.2.3).
Toensureanecientowofairinside,itisadvisable
tomounttheunitverticallyandprovidesucientspace
forventilationfromthelowerside.
The panel in which the Quad EtherCAT Microstepping
Drive is installed must be protected from dust and
liquids.
Figure 9.2.2 Unit insertion
Figure 9.2.3 Unit removal
