12. Available
accessories
Thefollowing accessoriesare availablefor drive code
1902503002 to enable input and output terminal
remotation:
- Boardcode2E000002ETC-QUADterminal
distributionboard
- Connectioncablesforterminaldistributionboard.
12.1 ETC-QUAD terminal
distribution board (code
2E000002)
Technicalspecications:
• AssemblyonDINguide
• Limiteddimensions
• Terminalsforinput,outputandI/Opowersupply
• IndicatorLEDs
• Connectorfordriveconnectioncable
XP1 Cabling towards ETC-QUAD (connector with
retaining tabs)
Table 12.1.1
Terminals for connection on eld
Fourrowsofterminals are envisaged to facilitate the
wiringofthesensorsandrelativepowersupplies:
- Upperrow:Inputsconnection
- Secondrow:Outputsconnection
- Thirdrow:Referenceconnection
- Fourthrow:24Vpowersupplyconnection
XP0 power supply connection
• 1 +24VI/O
• 2 REFI/O
Indicator LEDs
• Green LEDs I1…I16onwithactiveinputhigh,for
inputsIN1…IN16respectively.
• Red LEDs O1…O16 onwithactiveoutputhigh,
foroutputsOUT1…OUT16respectively.
12.2 Connection cables for
terminal distribution board
Thefollowingwiringisavailabletoconnecttheterminal
boardtotheQuad:
Code 70000032Pre-wiredcabletoconnectthe
terminaldistributionboard,length1.5M.
Code 70000033 Pre-wiredcabletoconnectthe
terminaldistributionboard,length3M.
Code 70000034 Pre-wiredcabletoconnectthe
terminaldistributionboard,length5M.
Allcablesareforxedinstallation,oil-resistant.
Pin-to-pinconnection.
SectionAWG24.
XP1
Name
1 Input 1
2 Input 2
3 Input 3
4 Input 4
5
Input 5
6 Input 6
7
Input 7
8 Input 8
9 Input 9
10 Input 10
11 Input 11
12 Input 12
13 Input 13
14 Input 14
15 Input 15
16 Input 16
33
+24V I/O
35
+24V I/O
37
+24V I/O
39
+24V I/O
XP1
Name
17
Output 1
18
Output 2
19
Output 3
20
Output 4
21
Output 5
22
Output 6
23
Output 7
24
Output 8
25
Output 9
26
Output 10
27
Output 11
28
Output 12
29
Output 13
30
Output 14
31
Output 15
32
Output 16
34
REF I/O
36
REF I/O
38
REF I/O
40
REF I/O
