SYSTEM Electronics ETC-QUAD UL - Connection

page 18
January 2020 - Rev. 1.2
Order Cod. 1902503003
Suggested connection diagram
11. Connections
11.1 UPPER SIDE TERMINALS
connection
Figure 11.1.1
XP10 POWER 24Vdc - Control board
24Vpowerconnector
1 +24Vdc
2 REF 24
3
4 GND
Maxcurrent0.5A
GND:Connecttothe
Ethernet ETH1 RJ45 (normally NOT used)
Thisconnectorfeaturesadust-proofcap.
• 1 TX+
• 2 TX-
• 3 RX+
• 4
• 5
• 6 RX-
• 7
• 8
87654321
L/A
LD4
RUN
LD3
ETC0
IN
L/A
LD5
ETC1
OUT
CAN
XP9
ACT
LD7
ETH1
LINK
LD6
XP10
GNDREF24
+24V
]
]
