4
3 Transportation and
storage
• Before you move the product to the installation location,
examine the packaging for damages�
• Do not move the product by the cables, terminal box, fan
impeller, protection grille, inlet cone or silencer�
• If lifting equipment is used, make sure that the lifting
equipment can hold the weight of the product� Refer to
the name plate for information� Do not lift the product by
the packaging�
• Keep the correct side of the packaging up during
transportation� Refer to the arrows on the packaging�
• Loadandunloadtheproductcarefully.
• Keep the product in a dry and clean location during
storage� Make sure that the ambient temperature during
storage is between –10 and +30 °C� A stable ambient
temperature prevents damage from condensation�
• Keep the product in storage for maximum 1 year�
• Turn the fan impeller manually each 3 months� Wear
approved protective gloves�
4 Installation
4.1 To do before the installation
of the product
• Make sure that you have the necessary installation
accessories:
– Refer to 14 Accessory overview page 19 for an
overview of the accessories�
– To decrease vibrations transmitted from the product to
the duct system, Systemair recommends to install
exibleconnections.
– If you install the product with free suction it is
necessary to install a protection grille� Make sure that
the safety distance agrees with the standard DIN EN
ISO 13857 and the standard DIN 24167–1�
• Useinstallationmaterialwithreresistanceratingforthe
installation location�
• Examine the packaging for transportation damage and
remove the packaging from the product carefully�
• Examine the product and all components for damage�
• Makesurethatthemotoreectandthefanperformance
agrees with the expectations at the installation location�
• Make sure that the information on the name plate and
the motor name plate agrees with the operation
conditions�
• Install the product in a location where there is space for
commissioning, troubleshooting and maintenance�
• Make sure that the installation location is clean and dry,
for full safety during electrical work�
• Makesurethattheinstallationsurfacehassucient
capacity to hold the weight of the product�
• Refertotheairowdirectionarrowsonthenameplateor
on the product to install the product in the correct
position�
• Make sure that all cable glands are tight against the
cables to prevent leaks�
Warning
Make sure that the product does not
become damaged or wet during
transportation� A damaged or wet
productcancausereorelectricshock.
Warning
Do not walk below a lifted product�
