SystemAir Fantech ATMO Series User Manual

37
SERVICE MANUAL
SERVICE MANUEL
SERVICE MANUAL ATMO SERIES
1 6/15/2021
11
1
2
10
8
3
9
4
5
7
6
BOM #
Description
ATMO 150H
(463888)
1
Motor
428515
2
MERV3, Electrostatic Filter Kit
463939
3
Heat or Energy Exchanger Cell
463098
4
Capacitor 6uF
411222
5
PC Board
428252
6
Speed Switch
410213
7
Transformer
411963
8
Drain Fitting Kit
463088
9
6” Dia. Plastic Collar
463102
10
6” Dia. Plastic Keeper
463103
Door Kit, ATMO Series
463941
Fuse, 8A, 250 VAC 3AB 3AG
414736
Temp Probe
461102
Kit, Chain
404261
Kit, Wall Bracket
463942
Wiring Diagram
463927
11
Installation Manual
463913
Filter MERV 8 (Pack of 2)
463943
Filter MERV 13 (Pack of 2)
463944
Kit, AUX. 24V Damper
463947
ATMO 200H
(463889)
428515
463940
463097
411222
428252
410213
411963
463088
463102
463103
463948
414736
461102
404261
463942
463927
463913
463945
463946
463947
ATMO 150E
(463890)
428515
463939
463937
411222
428252
410213
411963
463088
463102
463103
463948
414736
461102
404261
463942
463927
463913
463943
463944
463947
ATMO 200E
(463891)
428515
463940
463938
411222
428252
410213
411963
463088
463102
463103
463948
414736
461102
404261
463942
463927
463913
463945
463946
463947
