3.1 Dimensions and Weight
Fig. 2 Dimensions of left hand unit
The unit weight is 46 kg.
3.2 Connections Left and Right models
Fig. 3 Left and Right models
Position Description
R
Right hand model (Supply air connection
is situated on the right hand side of the
unit viewed from the front)
L
Left hand model (Supply air connection
panel is situated on the left hand side of
the unit viewed from the front)
Duct connections: Ø 125 mm
