SyScroll Air CO 40 to 75 - SLN Version
SyScroll AIR CO SLN
40 45 50 60 65 75
Power supply V/ph/Hz 400V/3/50Hz
Number of refrigerant circuits 1 1 1 1 1 1
Total capacity steps % 0-50-100 0-50-100 0-50-100
0-44-56-100
0-50-100 0-50-100
REFRIGERANT
Type R410A
Charge (1) kg 9.5 10.7 11.9 14.3 15.5 17.9
COMPRESSOR
Type Scroll
Number 2 2 2 2 2 2
Start-up type Direct
Oil type POE
N°of loading stages 0/100 0/100 0/100 0/100 0/100 0/100
EVAPORATOR
Type Plate
Number 1 1 1 1 1 1
Water flow rate l/s 1.8 2.0 2.3 2.8 3.0 3.5
Pressure drop kPa Refer to Hydraulic features
DESUPERHEATER
Type Plate
Number 1 1 1 1 1 1
Water flow rate l/s 0.50 0.55 0.64 0.74 0.81 0.95
Pressure drop kPa 17 21 20 23 20 26
FANS
Type Axial
Number 1 1 1 1 1 1
Nominal speed rpm 530 530 530 720 720 720
Air flow rate m³/s 3.05 3.05 2.86 4.4 4.4 4.4
Power input kW 0.57 0.57 0.57 1.27 1.27 1.27
AIR COOLED CONDENSER
Type Coil
Number 1 1 1 1 1 1
Total coil face area per coil m
2
2.6 2.6 2.6 3.2 3.2 3.2
Number of rows 2 2 3 3 3 3
HYDRAULIC CONNECTIONS (EVAPORATOR)
Type Threaded gas male
Inlet diameter inch
2” 2” 2” 2” 2” 2”
Outlet diameter inch
2” 2” 2” 2” 2” 2”
HYDRAULIC CONNECTIONS (DESUPERHEATER)
Type Threaded gas male
Inlet diameter inch
1” 1” 1” 1” 1” 1”
Outlet diameter inch
1” 1” 1” 1” 1” 1”
WEIGHT
Shipping weight kg 403 411 436 476 483 488
Operating weight kg 413 421 446 489 499 502
DIMENSIONS
Length mm 1750 1750 1750 2200 2200 2200
Width mm 1100 1100 1100 1100 1100 1100
Height mm 1580 1580 1580 1580 1580 1580
9 - Technical Data
(1) Indicative value. Always refer to the value specified on the unit’s label.
