9 - Technical Data
SyScroll Air RE Refrigerant Lines
SyScroll Air RE Unit
Unit connections Suction line dimensions [inch] Liquid line dimensions [inch]
Suction Liquid Total equivalent lenght [m] Total equivalent lenght [m]
[inch] [inch] 10 20 30 10 20 30
40 5/8” 1”3/8 1”3/8 1”3/8 1”3/8 7/8” 7/8” 7/8”
45 5/8” 1”3/8 1”3/8 1”3/8 1”5/8 7/8” 7/8” 7/8”
50 5/8” 1”3/8 1”3/8 1”3/8 1”5/8 1”1/8 1”1/8 1”1/8
60 7/8” 1”3/8 1”3/8 1”3/8 1”5/8 1”1/8 1”1/8 1”1/8
65 7/8” 1”3/8 1”3/8 1”5/8 1”5/8 1”1/8 1”1/8 1”1/8
SyScroll Air RE
Line length ø Suction line ø Liquid line R410A
[m] [inch] [mm] [inch] [mm] [Kg/m]
40
10 1”3/8 34,93 7/8” 22,23 0,34
20 1”3/8 34,93 7/8” 22,23 0,34
30 1”3/8 34,93 7/8” 22,23 0,34
45
10 1”3/8 34,93 7/8” 22,23 0,34
20 1”3/8 34,93 7/8” 22,23 0,34
30 1”5/8 41,28 7/8” 22,23 0,35
50
10 1”3/8 34,93 1”1/8 28,58 0,53
20 1”3/8 34,93 1”1/8 28,58 0,53
30 1”5/8 41,28 1”1/8 28,58 0,54
60
10 1”3/8 34,93 1”1/8 28,58 0,53
20 1”3/8 34,93 1”1/8 28,58 0,53
30 1”5/8 41,28 1”1/8 28,58 0,54
65
10 1”3/8 34,93 1”1/8 28,58 0,53
20 1”5/8 41,28 1”1/8 28,58 0,54
30 1”5/8 41,28 1”1/8 28,58 0,54
Data valid per each refrigerant circuit.
