Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
Frost
protection
Active
Cooling
recovery
No
Showsthestatusofthefrost
protectionfunction
Showsthestatusofthecooling
recoveryfunction
Externalset
point
Notactive
Showsthestatusofthe
externalsetpoint
→Alarmevents
Showsallregisteredalarms
alongwiththetimeanddate
theyoccurred
Movedownandupinthelistby
pressing↑↓
→Input/Output
→AI
Showsthestatusofthe
Ananlogueinputs
→DI
ShowsthestatusoftheDigital
inputs
→UI
ShowsstatusofUniversal
Analogueinputs
ShowsstatusofUniversal
Digitalinputs
→AO
Showsthestatusofthe
Analogueoutputs
→DO
ShowsthestatusoftheDigital
outputs
→Temperature
Extractair
temp
Act.:ºC
Setp:18.0ºC
Showsthecongured
temperaturecontrol(Defaultis
Extractairtemp)
Showstheactualtemperature
inthechosencontrolmode
Setthetemperatureforthe
chosencontrolmode
Ifcascade
control
Max/minsupply
setp.
Max:30ºC
Min:12.0ºC
Setthemaximumandminimum
allowedsupplyairtemperature
incaseofcascadecontrol
Logontoservicelevelneeded
tochangesettings
Outdoortemp:
ºC
Supplyairtemp
Actual:ºC
Setp:18ºC
Showstheactualoutdoorair
temperature
Showstheactualsupplyair
temperature
Showsthecalculatedsupply
airsetpoint.Theexhaust
aircontrolleroutputsignal
generatesthesupplyair
controller’ssetpointvalue
TopvexSR09,11,TR09-15OperationandMaintenanceInstructions
207880
11
SystemairAB
