Frost
protection
Actual:ºC
Showstheactualwater
temperatureinthewater
heatingbattery.(Onlyvisiblefor
HWunits)
Exhaustair
temp
Actual:ºC
Showstheactualexhaustair
temperature.
Efficiency
Exchanger
Actual:%
Output
Exchanger
Actual:%
Showstheactualheatrecovery
efciency
Thefunctioncalculatesthe
heatexchangerstemperature
efciencyin%whentheoutput
signaltotheexchangeris
higherthan5%andtheoutdoor
temperatureislowerthan10°C.
Whenthecontrolsignalis
lowerthan5%ortheoutdoor
temperatureishigherthan10°C
thedisplaywillshow0%.
→AirControl
Thismenuoptionbecomes
visibleiftheunitiscongured
for"Flowcontrol"or"Pressure
control"
Flowcontrol
SAF
Actual:m³/h
Setp.:m³/h
Showsairowforthesupplyair
fan(constantairowcontrol)
Onlyvisibleiftheunitis
conguredforFlowcontrol
Flowcontrol
SAF
Setp1/1:1100
m³/h
Setp1/2:550
m³/h
Setthenormal(1/1)and
reduced(1/2)airowforthe
supplyairfan
Outdoor
comp.Setp.1
—20°C=10m³/h
0°C=0m³/h
Act.Comp:0
m³/h
SettheSAFairow
compensationforthesettable
outdoortemperature.The
outdoorcompensationislinear
andissetusingtwoparameter
pairswhichgivethevalueofthe
compensationattwodifferent
outdoortemperatures.The
compensationcanbepositive
ornegative.
Showstheactualairow
compensation.
Flowcontrol
EAF
Actual:+INF
m³/h
Setp.:m³/h
Showsairowfortheextract
airfan(constantairowcontrol)
Onlyvisibleiftheunitis
conguredforFlowcontrol
TopvexSR09,11,TR09-15OperationandMaintenanceInstructions
