Page 34
Technical data
VLS BLN 904 1004 1104 1204
Power supply
V/ph/Hz
400 (±10%) / 3 / 50
Number of circuits 2 2 2 2
Capacity steps
%
28-50-78-100 25-50-75-100 23-50-73-100 25-50-75-100
Refrigerant
Type / GWP R410A / 2.088
Charge 1/2
(1)
kg
15/15 17/17 18/18 18/18
tCO
2
eq 31,3/31,3 35,5/35,5 37,6/37,6 37,6/37,6
Compressor
Type Scroll
Number 4 4 4 4
Start-up type Direct
N°of loading stages 0/100 0/100 0/100 0/100
Evaporator
Type Plate
Number 1 1 1 1
Water flow rate
l/s
10,9 12,0 13,4 14,7
Pressure drop
kPa
23,1 27,7 34,4 41,7
Water volume l 25,2 25,2 25,2 25,2
Condenser
Type Coil
Hydraulic connections
Type Threaded Gas Male
Inlet diameter
inch
3” 3” 3” 3”
Outlet diameter
inch
3” 3” 3” 3”
Weights
Shipping weight
kg
1745 1795 1810 1815
Operating weight
kg
1770 1820 1835 1840
Additional Weights
HSE*/HPF** versions kg 40 40 40 40
Desuperheater versions kg 30 30 30 30
With one pump kg 90 90 95 95
With two pumps kg 205 205 215 215
With pump and tank 500 lt kg 350 350 350 350
With pumps and tank 500 lt kg 400 400 400 400
Copper Fins kg 520 700 880 880
Dimensions
Length
mm
4300 4300 4300 4300
Width
mm
1100 1100 1100 1100
Height
mm
2300 2300 2300 2300
(1) The refrigerant value are indicative values for standard units. The actual data are indicated on the unit label.
(*) High Efficiency Units (HSE) with inverter fans.
(**) HPF Units with high static pressure fans.
