Page 33
English
Technical data
VLS BLN 524 604 704 804
Power supply V/ph/Hz 400 (±10%) / 3 / 50
Number of circuits 2 2 2 2
Capacity steps % 25-50-75-100 28-57-78-100 20-50-70-100 25-50-75-100
Refrigerant
Type / GWP R410A / 2.088
Charge 1/2
(1)
kg 7,8/7,8 8,2/8,2 15/15 15/15
tCO
2
eq 16,3/16,3 17,1/17,1 31,3/31,3 31,3/31,3
Compressor
Type Scroll
Number 4 4 4 4
Start-up type Direct
N°of loading stages 0/100 0/100 0/100 0/100
Evaporator
Type Plate
Number 1 1 1 1
Water flow rate l/s 6,5 7,4 8,5 9,5
Pressure drop kPa 28,3 36,1 47,5 49,1
Water volume l 11,5 11,5 11,5 13,3
Condenser
Type Coil
Hydraulic connections
Type Threaded Gas Male
Inlet diameter inch 2”1/2 2”1/2 2”1/2 2”1/2
Outlet diameter inch 2”1/2 2”1/2 2”1/2 2”1/2
Weights
Shipping weight kg 1083 1303 1478 1611
Operating weight kg 1095 1315 1490 1625
Additional Weights
HSE*/HPF** versions kg 30 30 30 30
Desuperheater versions kg 20 20 20 30
With one pump kg 50 50 85 85
With two pumps kg 140 140 200 200
With pump and tank 500 lt kg 350 350 350 350
With pumps and tank 500 lt kg 400 400 400 400
Copper Fins kg 380 380 520 520
Dimensions
Length mm 3300 3300 4300 4300
Width mm 1100 1100 1100 1100
Height mm 2300 2300 2300 2300
8.2 Technical data
(1) The refrigerant value are indicative values for standard units. The actual data are indicated on the unit label.
(*) High Efficiency Units (HSE) with inverter fans.
(**) HPF Units with high static pressure fans.
