Technical data
VLS ELN 904 1004 1104 1204
Power supply V/ph/Hz 400 (±10%) / 3 / 50
Number of circuits 2 2 2 2
Capacity steps % 28-50-78-100 25-50-75-100 23-50-73-100 25-50-75-100
Refrigerant
Type / GWP R410A / 2.088
Charge 1/2
(1)
kg 15/15 17/17 18/18 18/18
tCO
2
eq 31,3/31,3 35,5/35,5 37,6/37,6 37,6/37,6
Compressor
Type Scroll
Number 4 4 4 4
Start-up type Direct
N°of loading stages 0/100 0/100 0/100 0/100
Evaporator
Type Plate
Number 1 1 1 1
Water flow rate l/s 10,4 11,2 12,4 13,6
Pressure drop kPa 20,7 24,2 29,5 35,2
Water volume l 25,2 25,2 25,2 25,2
Condenser
Type Coil
Hydraulic connections
Type Threaded Gas Male
Inlet diameter inch 3” 3” 3” 3”
Outlet diameter inch 3” 3” 3” 3”
Weights
Shipping weight kg 1780 1835 1850 1855
Operating weight kg 1805 1860 1875 1880
Additional Weights
HSE* versions kg 40 40 40 40
Desuperheater versions kg 30 30 30 30
With one pump kg 90 90 95 95
With two pumps kg 205 205 215 215
With pump and tank 500 lt kg 350 350 350 350
With pumps and tank 500 lt kg 400 400 400 400
Copper Fins kg 520 700 880 880
Dimensions
Length mm 4300 4300 4300 4300
Width mm 1100 1100 1100 1100
Height mm 2300 2300 2300 2300
(1) The refrigerant value are indicative values for standard units. The actual data are indicated on the unit label.
(*) High Efficiency Units (HSE) with inverter fans.
