SystemAir VLS Series - Electrical, Fan, Pump Data, and Service Spaces

Page 61
English
VLS/VLH/VLC/VLR HPF 524 604 704 804 904 1004 1104 1204
Rated voltage V/ph/Hz 400 (±10%) /3/50
Max absorbed power kW 60,4 70,2 81,4 97,0 106,0 112,8 130,8 148,8
Rated current A 87,4 99,1 111,1 119,1 140,8 158,8 170,8 182,8
Max current FLA A 147,4 155,1 185,1 171,1 191,8 208,8 237,8 266,8
Max start-up current LRA A 270,4 279,1 349,1 356,1 376,8 432,3 484,8 513,8
External fuses A 200,0 200,0 250,0 250,0 250,0 250,0 315,0 315,0
Max cable section (*) mm
2
3x95 3x95 3x120 3x120 3x120 3x120 3x185 3x185
Exchanger Resistance
Rated voltage V/ph/Hz 230 (±10%) /1/50
Max absorbed power kW 130
Technical data
(*) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum
working temperature in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
Compressors Electrical Data
VLS/VLH/VLC/VLR 524 604 704 804 904 1004 1104 1204
Number
4 4 4 4 4 4 4 4
Nominal power input kW
(11,5+11,5)
x2
(12,5+12,5)
x2
(12,5+17,2)
x2
(15,9+15,9)
x2
(15,9+22,3)
x2
(22,3+22,3)
x2
(22,3+25,5)
x2
(25,5+25,5)
x2
Max. absorbed power kW
(14,0+14,0)
x2
(15,9+15,9)
x2
(15,9+21,5)
x2
(22,6+22,6)
x2
(22,6+26,0)
x2
(26,0+26,0)
x2
(26,0+35,0)
x2
(35,0+35,0)
x2
Rated current A
(35,0+35,0)
x2
(36,0+36,0)
x2
(36,0+51,0)
x2
(40,0+40,0)
x2
(40,0+48,5)
x2
(48,5+48,5)
x2
(48,5+63,0)
x2
(63,0+63,0)
x2
Max. current A (158+158) x2
(160+160)
x2
(160+215) x2
(225+225)
x2
(225+272)
x2
(275+272)
x2
(272+310)
x2
(310+310)
x2
Oil pan resistor W
(65+65)
x2
(75+75)
x2
(75+75)
x2
(120+120)
x2
(120+150)
x2
(150+150)
x2
(150+150)
x2
(150+150)
x2
