T.I.P. HWW 4400 INOX Plus Translation Of Original Operating Instructions

Translation of the Original Operating Instructions
2
Notes and instructions with the following symbols require particular attention:
Any non-observance of these instructions involves the danger of bodily harm to people and/or
damage to property.
Any non-observance of this instruction bears the risk of an electrical shock which may cause
damage to persons or property.
Please inspect the device for damage occurred during transportation. In case of damage, the retailer has to be
informed immediately, at the latest within 8 days after the date of purchase.
2. Technical Data
Model
HWW 4400 INOX Plus
Mains voltage / frequency
230 V~ / 50 Hz
Nominal performance
1000 Watt
Protection type
IPX4
Suction port
30.93 mm (1“), female
Pressure port
30.93 mm (1“), female
Max. flow rate (Q
max
)
4,350 l/h
1)
Max. pressure
4.5 bar
3)
Max. delivery height (H
max
)
45 m
1), 3)
Max. suction height
9 m
Volume of the pressure tank
22 l
Max. size of the solids being pumped
3 mm
Max. permissible operating pressure
6 bar
Min. ambient temperature
5 °C
Max. ambient temperature
40 °C
Min. fluid temperature
2 °C
Max. fluid temperature (T
max
35 °C
)
Max. cut-in frequency in one hour
40, evenly distributed
Length of connection cable
1.5 m
Cable type
H05RN-F
Weight (net)
12,7 kg
Guaranteed sound power level (L
WA
)
84 dB
2)
Measured sound power level (L
WA
)
82.4 dB
2)
Sound pressure level (L
pA
)
69.9 dB
2)
Dimensions (L x D x H)
49 x 28 x 53 cm
Item no.
31167
1)
2)
The values were determined with free, unreduced in- an outlet.
Noise emission values obtained according to the EN 12639 regulation. Measurement method according to EN ISO 3744.
Due to the factory pre-set switch off pressure of the pressure switch, pressure is limited to approx. 3 bar (30 m delivery head). The
theoretically achievable pressure of the pump unit of the domestic water supply can reach the value specified under “Max pressure”.
Consult a qualified specialist, to adapt the pressure circuit to your requirements if necessary, see also the chapter “Setting the pressure
switch”.
3)
3. Range of use
Booster sets from T.I.P. are self-priming electrical pumps with a mechanical or electronic pump control system for
automated operation. These high-quality products with their convincing performance data were developed for the
various purposes involved with irrigation, domestic water supply and pressure boosting, as well as for discharging
water at a constant pressure. The devices are suitable for pumping clean, clear water.
The typical areas of use of booster sets include: Automatic domestic water supply with grey water from wells and
cisterns, automated irrigation of gardens and garden beds and sprinkling, pressure boosting within the domestic
water supply system.
The device is not suitable for use in swimming pools or for installation in public water mains.
This product is intended for private use in the home area and not for commercial or industrial purposes or for
continuous circulating.
