IHB++ Series Technical Manual
- 16 -
After stable and zero indicator on, display will be show Load 2
Remove the third calibration mass weight from the pan
After stable and zero indicator on, display will be show Load1
Remove the second calibration mass weight from the pan
After stable and zero indicator on, display will be show load 0 Remove the
first calibration mass weight from the pan (*Note: Ensure the pan is empty)
After stable and zero indicator on, display will be will be start self checking.
After self checking display will come to normal weighing mode
*Note:
During the linear calibration steps LOAD 1 to LOAD 4, mass weights want to
add on the pan. Don’t remove all mass weights for the next step.
During the linear calibration steps LOAD 4 to LOAD 1, mass weights want to
reduce from the pan. Don’t remove all mass weights for the next step.
8.2 Normal calibration p2 cal
Press key to enter calibration, display will be show kg or lb, press key
to select the calibration unit kilograms or pounds, press key ,display will be
show unLoad.
Remove all the weight from the platform.
When scale get stable,display will be show load
Place the calibration weight (1/3 of the capacity) on the platform
After stable, scale will be calibrate automatically and will start self-test.
Note: Incase display will show any error message or incorrect measurement,
repeat the calibration again.
8.3 Manual calibration by built-in weight
In the weighing mode, press and hold key 3 seconds. The display will be
show XCALX , after 20 seconds, the display will be show PASS and come back
to the weighing mode.
8.4 Check internal counts F3 CNT
