T Scale ROW Series User Manual

ROW serial precision balance user’s manual
FUNCTION MENU SETTINGS
FUNCTION SUB-FUNCTION DESCRIPTION
DEFAULT
VALUE
bL Set the backlight to be on,
automatic or off,
EL on
EL Au
EL off
EL Au F3 off
bEEP Set the beep mode.(check
weighing mode 2, check weighing
mode3, no beep)
F4 Prt Set the RS-232 , at first set RS-232 working mode
(press TARE key to change, press ZERO key to sure)
P Prt: print weighing ticket when the M+ key is
pressed,
P Cont: send weighing data continuously, connect to
PC ,
ASK: ask and answer mode (bi-direction mode), connect
to PC.
Command “R”: send weighing data to PC
Command “T”: do tare operate
Command “Z”: do zero operate
P auto: auto M+ mode.
Sei re: also send continuously
Then set baud rate
After set working mode, display will show b xxx, this is
current baud rate, you select baud rate by TARE key ad
press ZERO to sure.
If you set printer (P PRT, P AUTO), then you can set print
out format.
Display will shows “PR x”, set the date/time M+ format,
Then display show “LAB x”, set gross/acc M+ format,
you can see detail below.
These parameter only available in MODE1(normal
mode), see detail in section 12.
Then set printer type,
TY-TP: mini ticket printer
TY 711: A711 label printer
LP-50: LP-50 label printer
P Prt
Prog Pin Enter the programming and calibration menus
by entering the correct password. See the
section 12.
-11-
