ROW serial precision balance user’s manual
SECTION 9 RS-232 OUTPUT
The ROW Series of scales can be ordered with an optional RS-232 output.
9. 1 basic information
Specifications:
RS-232 output of weighing data
ASCII code
8 data bits
No Parity
Baud rate from 600bps to 9600bps
9. 2 normal print out
Data Format for normal weighing operations, parts counting or recalling of totals from
memory will all be different. Examples follow:
Normal Output
When parts counting the weight, unit weight and count will be printed.
When recalling the Total weight stored in the accumulation memory the output format
is:
9. 3 continuously output protocol
con1: weighing mode
-14-
Date AND TIME The scale will be set date and time
S/N The number increments every time a new value is stored in memory
GW GW for gross weight, NT for net weight and a unit of weight
*************** A line of stars is shown
<lf> Includes 1 line feed
Date:
Time: 00:00
Total No: 3 Times of the accumulation memory
Total wt.: 0.447KG Weight of the accumulation memory
Date: The scale hasn’t printed
Time: 00:00 The scale will be set time
Gross wt: 0.149KG GW for gross weight, NT for net weight and a unit of weight
Unit wt: 7.4257G The average piece weight computed by the scale
Quantity : 20PCS The number of parts counted
<If>
