Air Chiller System (ACS) and Chiller Panel Getting Started Guide for the DMA 850 Page 43

4 Remove the 8 mm plug from the elbow on top of the cross connector by depressing the circumferential

ring and pulling on the plug.

Figure 40 Plug.

5 Install the Valve and Solenoid Upgrade Assembly onto the ACS using the (2) screws provided. .

Figure 41 Valve and Solenoid Upgrade Assembly installed.
