tae TA Series

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 7
08: Digital I/O
ID
Name
Value-Range
Default-Value
Unit
Access
200
DI-Physical
0000h ... 0F3Fh
---
[bits]
R
Physical state of the digital inputs.
0=low, 1=high
Bit
Name
Notes
0
Terminal 52
1
Terminal 53
2
Terminal 54
3
Terminal 55
4
Terminal 56
5
Terminal 57
6
7
8
Terminal 2
9
Terminal 3
10
Terminal 4
11
Terminal 5
12
13
14
15
08: Digital I/O
ID
Name
Value-Range
Default-Value
Unit
Access
201
Master/Slave DI
0000h ... 000Fh
---
[bits]
R
Physical state of the inputs.
0=low, 1=high
Bit
Name
Notes
0
Z0 Master
Zero impulse from the Master drive
1
Z0 Slave
Zero impulse from the Slave drive
2
AI Master
A-track from the Master drive
3
BI Master
B-track from the Master drive
