tae TA-U110 User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 24
16: Master/Slave
ID
Name
Value-Range
Default-Value
Unit
Access
670
MaSlv Ctrl
0000h ... FFFFh
0000h
[bits]
RW
Controlling the Master/Slave operating modes
Bit
Name
Note
0
Slave Function
Activate
1
Master with single track On Tr. B
Only functions with connection with input Track B, Connection
Track A is used to define direction of rotation.
2
Exchange Master Signals A-B
Slave’s direction of rotation is inverted and Par.680 Master Impulse
Meter changes direction
3
Synchron Angle Not Speed
Angle deviations are readjusted taking the preset ratios into
consideration
4
Slave Angle Correction
Enables angle correction (Par.674)
5
Change Slave Direction
Slave drive switches direction of rotation
6
Limit Master Pulse By ILimit
Impulse differences during current threshold are not readjusted!
7
Limit Master Pulse By Maxspeed
Impulse differences during maximum rotational speed are not
readjusted!
8
Exchange Slave Signals A-B
To adapt the AB tracks of the motor.
9
Reset Counter
Par.680/681 (Current Master or Slave impulses) are reset.
10
Enable Sync On Motor Shaft (Z0)
2 machines are angularly synchronised with the motor shafts using 2
zero impulses
11
Enable Sync with Initiators (2Ini)
2 machines are randomly angularly sunchronised using 2 additional
standard initiators.
12
Enable Electromagnetic Coupling (2 Ini)
Load will be switched on via electromagnetic coupling
13
Measure Master/Slave ratio (2 Ini)
Ascertains impulse ratio between Master and Slave according to
gears.
14
Measure Master/Slave Impuls relation (2 Ini)
The Master and Slave ratio will be defined according to the impulse
ratio
15
Get absolute Position of Slave (Z0)
Registers the offset of the slave motor to the master motor
