Instruction and Operating Manual

TA-U1...U280

Misprints and technical changes reserved

3.3.2 Powerstage TA-U8..U15

X13

BR1

LD1

LD2

LP1

BR2

X14

LP2

LP3

X12

X1 Connection to controlboard

X6 +/-24V

X7 +/-24V

X8 Charging relay

X12 PT100/Thermal switch

X13 Safe Stop

X14 Buss voltage

BR1 Mains voltage 200-250V

BR2 Indication Safe Stop bridged

BR3 Safe Stop bridged

LD1 Buss voltage „Red“ back side

LD2 Power supply active „Green“ back side
