tae TA-U65 HT

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 8
08: Digital I/O
ID
Name
Value-Range
Default-Value
Unit
Access
202
DI-Logical
0000h ... 0F3Fh
---
[bits]
R
Logical state of the inputs.
0=low, 1=high
Bit
Name
Notes
0
Terminal 52
1
Terminal 53
2
Terminal 54
3
Terminal 55
4
Terminal 56
5
Terminal 57
6
7
8
Terminal 2
9
Terminal 3
10
Terminal 4
11
Terminal 5
12
13
14
15
08: Digital I/O
ID
Name
Value-Range
Default-Value
Unit
Access
210
DO Set
0000h ... 031Fh
0000h
[bits]
RW
The digital outputs can be set manually. (e.g. for the purpose of checking the signal)
0=low, 1=high
Bit
Name
Notes
0
Terminal 60
1
Terminal 61
2
Terminal 63
3
Terminal 64
4
Terminal 65
5
6
7
8
Terminal 11
9
Terminal 13
10
11
12
13
14
15
