tae TA-U65 HT User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 9
08: Digital I/O
ID
Name
Value-Range
Default-Value
Unit
Access
211
DO Set Actual
0000h ... 031Fh
---
[bits]
R
Current state of the digital outputs.
0=low, 1=high
Bit
Name
Notes
0
Terminal 60
1
Terminal 61
2
Terminal 63
3
Terminal 64
4
Terminal 65
5
6
7
8
Terminal 11
9
Terminal 13
10
11
12
13
14
15
09: Analog I/O
ID
Name
Value-Range
Default-Value
Unit
Access
220
A-IN 8 Mode
[00] 0~10V ... [02] 4~20mA
[00] 0~10V
RW
Analog input terminal 8:
Selecting the physical input parameter. (unipolar)
Analog inputs are configured to a voltage in the factory; when used as a current input (e.g. 4-20mA), the dip
switch position of the input has to be altered! (See wiring diagram)
Nr.
Name
Notes
0
0-10V
1
0-20mA
2
4-20mA
09: Analog I/O
ID
Name
Value-Range
Default-Value
Unit
Access
221
A-IN 8 Offset
0 ... 32767
---
RW
222
A-IN 8 Gain
0,00 ... 105,00
---
RW
223
A-IN 8 Dest-Parameter
0 ... 65535
521
RW
224
A-IN 8 Act Value
0 ... 32767
---
R
