21
English
Installation
nuts and bolts. Reduce the hole size if using self-tapping
screws in metal that is less than 1mm thick.
Drill any additional holes required for cables and fit them
with suitable grommets or bushings.
Secure the metal cradle cover to the mounting points
with the M5 self-tapping screws supplied, or with M5
nuts and bolts. Ensure that tightening the screws or
bolts does not distort the cradle.
Figure 4: Mounting
