TB7100 Service Manual Frequency Synthesizer Fault Finding 169
© Tait Electronics Limited October 2005
Figure 11.9 Synthesizer circuitry under the
SYN TOP and VCO TOP cans (UHF radio, top side)
Tx port
Junction of
C541 and R547
Rx port
Q507 Q506 Q508
