TB7100 Service Manual Disassembly and Reassembly 99
© Tait Electronics Limited October 2005
7 Disassembly and Reassembly
This section describes how to:
■ remove and open and close the base station
■ remove and fit the modules and components
■ disassemble and reassemble the transmitter module
General Important Before disassembling the base station, disconnect the base
station from any test equipment or power supply.
Disassemble only as much as necessary to replace the defective parts.
Inspect all disassembled parts for damage and replace them, if necessary.
Observe the torque settings indicated in the relevant figures.
For information on spare parts, refer to “Spare Parts” on page 369.
Important To ensure adequate airflow through the base station, do not
cover the fan intake grill on the front panel. Do not operate
for more than a few minutes with the fan intake covered.
Important The transmitter and receiver modules can only be replaced
with base station modules. The transmitter module can be
identified by the heat transfer plate fitted to the underside,
whereas the receiver does not have a heat transfer plate.
