TB7100 Service Manual Frequency Synthesizer Fault Finding 183
© Tait Electronics Limited October 2005
Figure 11.12 Synthesizer circuitry under the
SYN TOP can (VHF radio, top side)
Tx port
Junction of
C541 and R547
Rx port
