TB7100 Service Manual Receiver Fault Finding 203
© Tait Electronics Limited October 2005
Figure 12.1 Receiver circuitry under the
IF TOP can (top side)
Q404
H5/H6 bands
Measurement point
B1 band
Q404 Measurement point
