244 Transmitter Fault Finding (25W) TB7100 Service Manual
© Tait Electronics Limited October 2005
Figure 13.10 PA circuitry under the
PAF TOP can
H5, H6 BANDS
B1 BAND
CICUITRY BETWEEN IC301 AND PAs
(H5 AND H6 BANDS SIMILAR)
VIA TO GATE OF Q309
VIA TO GATE OF Q310
VIA TO PIN 14 OF IC301
VIA TO PIN 8 OF IC301
PAF TOP
PAF TOP
