TB7100 Service Manual Transmitter Fault Finding (25W) 251
© Tait Electronics Limited October 2005
Figure 13.11 PA driver circuitry under the
PAD TOP can
B1 band
Components
C310, R324, R327
Gate of Q306
Components
C310, R324, R327
Gate of Q306
H5/H6 bands
