TB7100 Service Manual Transmitter Fault Finding (50W/40W) 279
© Tait Electronics Limited October 2005
Figure 14.3 Point for measuring the power supply to the PAs (H5 and H7 bands)
PAF TOP
H5, H7 BANDS
Q310
Q309
L310
MEASUREMENT POINT ON L310
