336 Transmitter Fault Finding (50W/40W) TB7100 Service Manual
© Tait Electronics Limited October 2005
Figure 14.26 Circuitry under the
PIN TOP can, and points for attaching the test lead and test capacitor
H5, H7 BANDS
B1 BAND
C361
C362
C363
D307
C361
C362
C363
D3507
TEST PAD
TEST PAD
MOUNTING POINT FOR
TEST CAPACITOR
