14 Base Station Specifications TB9400 Specifications Manual
© Tait Limited July 2017
Outputs
28VDC output
Voltage
Current
Regulation
Ripple and noise
a
Ripple and noise rms
Transient response on 28V loadstep
b
28V
14A maximum
±0.5%
50mV pp
10mV rms
2% overshoot and recover within 0.6ms
a. 100MHz bandwidth.
b. 10% to 100% loadstep.
Protection
Overload
Short circuit
Overvoltage
AC module
DC module
electronic current limit above 16A
hiccup mode, self-resetting
electronic shutdown latch (33.5V)
electronic hysteric control (33.5V)
Auxiliary Power Supply
DC input voltage 28V ±15%
DC output
Voltage
Current
Regulation
Ripple and noise
a
Ripple and noise rms
Zero load ripple
12V
13.65V
3A maximum
±2%
50mV pp
10mV rms
100mVpp
24V
27.3V
1.5A maximum
±2%
50mV pp
10mV rms
100mVpp
48V
54.6V
750mA maximum
±2%
50mV pp
10mV rms
100mVpp
a. 100MHz bandwidth.
Protection
Overload/short circuit
Overvoltage
12V
electronic
current limit
16V Zener diode
24V
electronic
current limit
32V Zener diode
48V
electronic
current limit
62V Zener diode
General
Efficiency at rated output
Input-to-output isolation
Output-to-chassis isolation
88%
1000VAC, 50Hz, 1 minute
500VAC, 50Hz, 1 minute
