86 General Information TM8100 Mobile Radio Service Manual
May 2004 © Tait Electronics Limited
Spares Kits The spares kits required for the servicing of the radio are listed in
Table 4.4. The corresponding repair levels are also indicated. A spares
kit (Spares kit 6) for the repair of the rugged microphone is also supplied
but is not discussed in this manual; refer to the accessories manual for the
details. The contents of Spares kits 1, 2 and 10 are given in Section 6
(on page 125). Contents lists for Spares kits 4 and 5 are supplied with
the kits.
Table 4.4 Spares kits
Kit number Product code Description Repair level
1 TMAA22-01 Parts of two-digit-display control head
— excluding control-head board
1
2 TMAA22-02 Mechanical parts of radio body 1
3 TMAA22-03 Control-head boards (two-digit display) 1
4 TMAA22-04 Selected components of control-head boards 2
5 TMAA22-05 Selected components of main board 2
7 TMAA22-07 Control-head seals 1
10 TMAA22-90 Parts of one-digit-display control head
— excluding control-head board
1
11 TMAA22-91 Control-head boards (one-digit display) 1
TMAA22-12B1 Main-board assembly (B1 band) 1
TMAA22-12H5 Main-board assembly (H5 band) 1
TMAA22-12H6 Main-board assembly (H6 band) 1
