TM8100/TM8200 Service Manual Introduction 13
© Tait Electronics Limited June 2006
1 Introduction
The TM8100 and TM8200 series is a range of high-performance
microprocessor-controlled radios for analog voice and data communication.
The radios are designed for installation in vehicles but can also be used in
desktop, remote-monitoring and similar applications.
This manual includes the information required for servicing the radio and
its accessories.
This section describes the different options available for:
■ frequency bands
■ RF output power
■ accessories
■ product codes.
This section also gives an overview of the labels on the product and the
specifications.
Figure 1.1 TM8200 mobile radios
TM8235 radio with 3-digit-display control head
TM8250 or TM8255 radio with graphical-display control head
TM8252 radio with RJ45 control head
