184 Frequency Synthesizer Fault Finding TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 9.2 Synthesizer circuitry under the SYN TOP can and the 6 V regulator IC606 (top side)
VHF bands
UHF bands
Measurement
point on L506
(pin not used)Pin 5 (5-pin device)
Q508
Q507
Q506
Q508
Q512
Q512
Q508
Q5004
A4 band differences
SMPS output (C531 and
R530 are on the bottom side
of the PCB)
