TM8100/TM8200 Service Manual Frequency Synthesizer Fault Finding 197
© Tait Electronics Limited June 2006
Figure 9.8 Synthesizer circuitry under the SYN TOP can (top side)
VHF bands
UHF bands
Q512
Q512
Junction of
C541 and R547
Junction of
C541 and R547
TP503
TP503
