220 Frequency Synthesizer Fault Finding TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 9.13 Synthesizer circuitry under the SYN TOP can (VHF radios, top side)
Tx port
Junction of
C541 and R547
Rx port
