268 Transmitter Fault Finding (40W/50W) TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 11.4 Test points for checking the 9V supply, the forward and reverse RF power, and the
inhibiting of the transmitter
VHF UHF IF TOP CAN
VCO TOP CAN
IF TOP CAN
DIRC TOP CAN DIRC TOP CAN
D TX INH TEST POINT TX INH TEST POINT
TX INH TEST POINT
9V0 TX TEST POINT
9V0 TX TEST POINT
REV PWR TEST POINT
REV PWR TEST POINT
FWD PWR TEST POINT
FWD PWR TEST POINT
GND TEST POINT
