286 Transmitter Fault Finding (40W/50W) TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 11.10 PA circuitry under the PAF TOP can (UHF shown)
H5, H7 BANDS
Q310
Q309
CIRCUITRY BETWEEN
IC301 AND PAs
VIA TO GATE OF Q310
VIA TO GATE OF Q309
VIA TO PIN 14 OF IC301
VIA TO PIN 8 OF IC301
