294 Transmitter Fault Finding (40W/50W) TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 11.12 PA driver circuitry under the PAD TOP can (UHF)
PAD TOP
H5, H7 BANDS
Q306
R324
C310
R327
GATE OF Q306
COMPONENTS C310,
R324 AND R327
