312 Transmitter Fault Finding (40W/50W) TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 11.19 Components of the interstage matching circuitry between the PA driver Q306 and the
PAs Q309 and Q310 (UHF)
H5, H7 BANDS
Q310
Q309
Q306
PAF TOP CAN PAD TOP CAN
