338 Transmitter Fault Finding (25W) TM8100/TM8200 Service Manual
© Tait Electronics Limited June 2006
Figure 12.6 PA circuitry under the PAF TOP can and part of the directional coupler under the DIRC TOP
can (VHF shown)
PAF TOP
D301
Q310
Q309
D1 BAND
TEMPERATURE SENSOR
C350
C349
C348
MOUNTING POINT
FOR TEST CAPACITOR
TEST PAD
DIRC
TOP
SOLDER OUTER
SHEATH TO GND
