TM8100/TM8200 Service Manual Transmitter Fault Finding (25W) 363
© Tait Electronics Limited June 2006
Figure 12.14 PA driver circuitry under the PAD TOP can (UHF shown)
Synthesizer output at C300
Exciter output at C301
Driver output
Buffer output at C313
