TM8100/TM8200 Service Manual CODEC and Audio Fault Finding 387
© Tait Electronics Limited June 2006
Figure 13.3 Circuitry under the CDC TOP can, and adjacent interface circuitry
Junction of
R234 and R235
Junction of
R708 and C706
